Vibration graphite

Inquiry This Item

Description

VSK Series fine grain graphite has an exceptionally homogeneous structure, almost isotropic properties and low ash content. It can be manufactured in large sizes. Further processing, for example impregnation is possible. VSK Series graphite can be widely applied in metallurgical, machinery, electronics, chemical, and so on.

Technical data and Typical specifications

VSK Series fine grain graphite has an exceptionally homogeneous structure, almost isotropic properties and low ash content. It can be manufactured in large sizes. Further processing, for example impregnation is possible. VSK Series graphite can be widely applied in metallurgical, machinery, electronics, chemical, and so on.

Technical data and Typical specifications

temBulk Density (g/cm3) Min.Grain size (mm) MaxSpecific Resistance (μΩ.m) Max.Flexible Strength (MPa) Min.Compressive Strength (Mpa) MinC.T.E (×10-6/℃) MaxAsh Content (%) Max.
VSK-1 1.72 0.8 8.5 13.5 30.0 2.5 0.3
VSK-2 1.71 2.0 8.5 13.0 28.0 2.5 0.3
VSK-3 1.60 2.0 9.0 7.8 20.0 2.3 0.3
VSK-4 1.58 4.0 10.0 7.5 20.0 2.3 0.3

Typical specifications (mm):

332×150×2200, 350×175×2100, 500×200×1800, 500×200×2500, 550×250×1800, 550×250×2500, 400×400×1800, 600×200×1830, 508×508×1900, 540×300×2600, 300×850×1900, 900×900×1800, Φ630- Φ1420×600, and also we can produce as per your requirements for the sizes.
